تفاصيل المنتج:
|
|
| مكان المنشأ: | الصين |
|---|---|
| اسم العلامة التجارية: | KERSTERN |
| إصدار الشهادات: | ISO9001 |
| رقم الموديل: | 6000 سلسلة KM6B |
|
شروط الدفع والشحن:
|
|
| الحد الأدنى لكمية: | 1 جهاز كمبيوتر |
| الأسعار: | According to order quantity |
| تفاصيل التغليف: | كرتون وصندوق خشبي |
| وقت التسليم: | 7 أيام عمل |
| القدرة على العرض: | 10000 قطع شهريا |
|
معلومات تفصيلية |
|||
| نوع المحرك: | المحرك المداري | حالة: | جديد |
|---|---|---|---|
| الاستخدام: | جهاز الحفر، حفارة | حزمة النقل: | صندوق خشبي/صندوق كرتون |
| آلة التطبيق: | حفارة صغيرة/آلة إزالة الأعشاب/شاحنة القمامة | تخفيف: | فرشاة |
| إبراز: | High torque hydraulic wheel motor,Hydraulic wheel motor 205 bar,Heavy duty hydraulic wheel motor,Hydraulic wheel motor 205 bar,Heavy duty hydraulic wheel motor |
||
منتوج وصف
Applications
These motors can be used in industrial machines (e.g. conveyors), mining machinery (e.g. drills, winches), working machines (e.g. bulldozers, crushers) and in shipbuilding industry (e.g. control systems, propellers) etc.
Advantages
1. Low start-up pressure;
2. Shaft seal can bear high back pressure;
3. The motor can be used in parallel or series configuration;
4. Distribution system can meet the requirements of low noise units;
5. Compact volume and easy installation;
6. High torque.
KM6B Brake motor
KM6B motor is KM6 brake motor with multi-disc brake that is released by a hydraulic pressure ,and has good brake performance ,the motor has same work performance as BM6 when the brake is released.
Main Specification
| Displacement | 195 | 245 | 310 | 395 | 490 | 625 | |
| (ml/r) | |||||||
| Release pressure | 25 | 25 | 25 | 25 | 25 | 25 | |
| (bar) | |||||||
| BrakeTorque (NM) <=800 | <=800 | <=800 | <=800 | <=800 | <=800 | ||
| Max pressure (bar) | 205 | 205 | 205 | 205 | 170 | 140 | |
| Max Flow(LPM) | 150 | 150 | 150 | 150 | 150 | 150 | |
Note:
1, Don’t work over the max pressure
2, The drain port must be connected to the return circuit 3, Don’t brake when the motor is dynamic status
4, If the system has pilot pump,use pilot oil to open the brake, otherwise , the working pressure don’t exceed 150 bar.
5, The oil temperature don’t exceed 80℃
6,Oil recommended: Anti-wear hydraulic oils , viscosity at least 13cSt in working .
Packing:
1. who are we?
We are based in Jining China, start from 2003
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3. what can you buy from us?
Hydraulic motor
4. How long is the Warranty?
One-year warranty.
5. What is your payment terms?
Re: 100% in advance, long-term dealer 30% in advance, 70% beofre shipping.
6. How about the delivery time?
Normal Models within 2 days, unusual models and bulk order within 5-10 days.
